Cell Model | Prismatic 3.2V100Ah |
Rated capacity | 100AH |
Rated voltage | 48V |
Size | 440 * 440 * 133mm / metal case |
Charge cut-off voltage | 54V |
Discharge cut-off voltage | 40.5V |
Weight | About 45kg |
Standard charging current | 50A |
Standard discharge current | 100A |
Charging temperature | 0~55℃ |
Discharge temperature | -20~60℃ |
Storage temperature | -20~45℃ |
Cycle life | ≥6000 times |
Communication | CAN/RS485/RS232 |
telecom base station energy storage
Home energy storage
1、Cabinet-type standard design, easy to install and connect in series
2、The display shows parameters such as power and voltage, which is concise and clear.
3、Compatible with multiple communication interfaces
4、Brand new A-grade cells from major manufacturers, with good consistency, guaranteed service life and safety
